妙用与简单/Brief Introduction：

机器是充当服用液窗户磨砂玻璃容器的新产品上市设备，彻底消除解決了过往服用液窗户磨砂玻璃容器的不好的感觉。这类的灌封机所配的塑胶板材瓶，就不须要洗瓶机、烘烤机，更不须要空气消毒，能直接的灌封。设备全智能理瓶、进瓶、装罐，装罐量平稳，无漏滴，无瓶不装罐。上盖、封膜率能够达到100%。此机技术设备现进，体积大概小、启用平稳、燥音低，使用维修培训、冲洗快捷等优点和缺点，完完全全具有GMP标准规定。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款型有低速度和绕城高速俩种时产供您首选。Note: this model has two kinds of low speed and high-speed production for your choice.

优势 Characteristic

◆滤油机常用在多种多样易折瓶口服药液压力容器检验分装和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆所有电气开关元件均分为有名气国际品牌。All electrical components adopt famous brand◆远程服务器操作方法精确性以便于，无瓶不灌装设备，剂量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料管瓶灌封机的包括节构与原因Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折金属瓶灌封机基本理瓶器、理盖器、主转动系统性、同时带缝隙送小瓶置、空罐检漏器、灌装设备医院、排除器、热熔胶封医院、汽动设备手腕夹瓶医院、步进驱动器调速电机缝隙上瓶医院与出瓶医院等组成了。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机器人动用的服食液易折朔料瓶、盖一定清洁区出产的，应为药袋材许证书证，于是瓶身与底盖经传输和"去业务外包"后可真接进去灌封间。凭借理盖器、理瓶器的主动定位归类，剔出反向的方式给回底盖及瓶身底口朝下的瓶，使定位后的包材喂料有规责地进去推送在轨道中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定项后液体液易折塑胶板材瓶在气力输送机轨道列车总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

技木参数表technical parameters：

型号model	NLGFY-40	NLGFY-80
装量条件The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
塑封率Hot sealing intensity	》99%
装量测量误差The load error	《1.5%
碰坏率damage rate	《1.0%
热效率power	2KW	3KW
电源线Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
容量 Weight	700Kg	800Kg
